Electronic safety
pure sine wave for safe operation of sensitive devices such as laptops, TVs, medical equipment, and heating boilers.
New!
Inverter Generator KS 9500iE S ATSR
€2.183,95
Inverter Generator KS 9500iE S ATSR
€2.183,95
Inverter Generator KS 9500iE S ATSR
Available
€2.183,95
Specification
| Voltage, V: | 230 |
| Max power, kW: | 9.5 |
| Nominal power, kW: | 9.0 |
| Engine start: | Manual/electric/remote |
| Outlets: | 1 x Schuko 230 V, 1 x CEE 230 V 32 A, 1 x CEE 230 V 63 A |
Specification
| Voltage, V | 230 |
| Max power, kW | 9.5 |
| Nominal power, kW | 9.0 |
| Power factor, cosφ | 1 |
| Frequency, Hz | 50 |
| Current (max), A | 41.3 |
| Outlets | 1 x Schuko 230 V, 1 x CEE 230 V 32 A, 1 x CEE 230 V 63 A |
| Engine start | Manual/electric/remote |
| Fuel tank volume, l | 30 |
| Runtime at 50% load, h*** | 10 h 15 min |
| LED display | Multifunctional |
| Noise level Lpa (7m)/Lwa, dB | 70/95 |
| Power output DC, V/А | 12V/8.3A |
| USB-Outputs | QC 3.0 + Type C |
| Engine model | KS 480i |
| Engine cylinder volume, cm3 | 438 |
| Engine type | Gasoline powered one-cylinder, four-stroke air-cooled |
| Engine power, hp | 14.2 |
| Output for ATS | + |
| Crank case volume, l | 1.2 |
| Accumulator (A·h) | 3 |
| Alternator winding | Copper |
| Protection class | IP23M |
| Includes | Generator, Packaging, Manual, Spark plug wrench, Accessory pouch, PH2 6.0 mm screwdriver, Handle, 2×Wheels, Remote control, Battery charging cable, Oil funnel |
| Gross dimensions (LxWxH), mm | 905×715×815 |
| Net weight, kg | 85 |
| Gross weight, kg | 85.0 |
| SKU | KS 9500iE S ATSR |
| Barcode | 4260405367184 |
Benefits
Features
01
High power
02
Inverter technology
03
Quiet operation
04
Automatic backup power
05
Remote control
06
External control via dry contacts
07
Start/Stop button
08
USB ports
09
Extended runtime
10
EU compliance
High power
9.5 kW maximum output, ideal for home, office, and construction site backup.
Inverter technology
Pure sine wave ensures safe operation of sensitive electronics.
Quiet operation
Noise level ~70 dB, suitable for residential and open spaces.
Automatic backup power
ATS connection enables seamless operation during outages.
Remote control
Convenient start and stop of the generator from a distance.
External control via dry contacts
Integration with automation and backup systems.
Start/Stop button
Quick and simple starting.
USB ports
Convenient connection and charging of mobile devices without additional adapters.
Extended runtime
About 10 hours on a single 30 L tank reduces refueling frequency.
EU compliance
Meets Euro 5 requirements.
Benefits
Quiet operation
the enclosed sound-absorbing casing provides ~70 dB, quieter than most open-frame generators.
Convenient and quick start
remote control allows operation from a distance.
Integration with automatic systems
remote control allows operation from a distance.
Easy start
Start/Stop button ensures quick generator start and stop.
Convenient charging of mobile devices
USB ports allow connecting gadgets without extra adapters.
Efficient engine
powerful engine and 30 L tank ensure 10 hours of operation at 50% load.
Portability and convenience
wheels and handle for easy movement.
Certified and reliable
Euro 5 compliance and 2-year warranty.
Fuel level indicator
shows the amount of fuel in the tank for monitoring and timely refueling when the generator is off.
Transport handle and wheels
simplify generator movement.
Anti-vibration feet
reduce vibration during operation, increasing stability and reducing noise.
START/STOP button
allows you to start or stop the generator.
Battery charging socket
used for charging the generator’s battery
Economy Mode switch
reduces engine speed to lower fuel consumption and noise at low loads
AC RESET button
restores power after overload protection activation
Multifunctional LED display
shows main operating parameters
Connection for external ATS module
enables automatic generator start during power outages.
Socket overload protection
prevents socket damage
230V 16A Schuko socket
for connecting standard household devices
Grounding bolt
grounding connection for the generator
230V 63A CEE socket
for connecting high-power electrical equipment
230V 32A CEE socket
for connecting energy-demanding appliances
USB outputs 2×5V Type A/Type C
for charging mobile devices and gadgets without extra adapters
External control connection
allows connecting external generator control systems
12V/8.3A DC socket
for powering and charging 12V batteries and equipment
Remote control synchronization button
activates or deactivates remote generator control
Fuel level indicator
shows the amount of fuel in the tank for monitoring and timely refueling when the generator is off.
Transport handle and wheels
simplify generator movement.
Anti-vibration feet
reduce vibration during operation, increasing stability and reducing noise.
START/STOP button
allows you to start or stop the generator.
Battery charging socket
used for charging the generator’s battery
Economy Mode switch
reduces engine speed to lower fuel consumption and noise at low loads
AC RESET button
restores power after overload protection activation
Multifunctional LED display
shows main operating parameters
Connection for external ATS module
enables automatic generator start during power outages.
Socket overload protection
prevents socket damage
230V 16A Schuko socket
for connecting standard household devices
Grounding bolt
grounding connection for the generator
230V 63A CEE socket
for connecting high-power electrical equipment
230V 32A CEE socket
for connecting energy-demanding appliances
USB outputs 2×5V Type A/Type C
for charging mobile devices and gadgets without extra adapters
External control connection
allows connecting external generator control systems
12V/8.3A DC socket
for powering and charging 12V batteries and equipment
Remote control synchronization button
activates or deactivates remote generator control
Specification
Inverter Generator KS 9500iE S ATSR
| Voltage, V | 230 |
| Max power, kW | 9.5 |
| Nominal power, kW | 9.0 |
| Power factor, cosφ | 1 |
| Frequency, Hz | 50 |
| Current (max), A | 41.3 |
| Outlets | 1 x Schuko 230 V, 1 x CEE 230 V 32 A, 1 x CEE 230 V 63 A |
| Engine start | Manual/electric/remote |
| Fuel tank volume, l | 30 |
| Runtime at 50% load, h*** | 10 h 15 min |
| LED display | Multifunctional |
| Noise level Lpa (7m)/Lwa, dB | 70/95 |
| Power output DC, V/А | 12V/8.3A |
| USB-Outputs | QC 3.0 + Type C |
| Engine model | KS 480i |
| Engine cylinder volume, cm3 | 438 |
| Engine type | Gasoline powered one-cylinder, four-stroke air-cooled |
| Engine power, hp | 14.2 |
| Output for ATS | + |
| Crank case volume, l | 1.2 |
| Accumulator (A·h) | 3 |
| Alternator winding | Copper |
| Protection class | IP23M |
| Includes | Generator, Packaging, Manual, Spark plug wrench, Accessory pouch, PH2 6.0 mm screwdriver, Handle, 2×Wheels, Remote control, Battery charging cable, Oil funnel |
| Gross dimensions (LxWxH), mm | 905×715×815 |
| Net weight, kg | 85 |
| Gross weight, kg | 85.0 |
| SKU | KS 9500iE S ATSR |
| Barcode | 4260405367184 |
